Question Cant overclock Ram

[masalcii67]

hi, my ram is currently running on 2400Mhz i want to overclock this to 3200Mhz.
i have installed the latest bios update on my motherboard, butt when enable XMP Profile 1 or 2 it doesn't boot up???
what is the problem here???

my system:
AMD Ryzen 9 3900x
Msi MPG X570 Gaming Edge Wifi
16GB Ram Hyperx Fury
RTX 2060 SUPER
Crucial P1 M.2



[Kaamos_Llama]

Are the sticks rated for 3200?

RAM can be finnicky. It's more than likely your motherboard/CPU doesnt like the XMP settings even if they are rated for that. First try clearing CMOS. How to do this should described in your motherboards manual. If that doesnt help then you could run a Memtest or other things to make sure you dont just have bad sticks.

How to Test RAM: Making Sure Bad Memory Isn't Crashing Your PC

If you've got a nasty case of blue screens of death, you should check if your RAM is working properly.

www.tomshardware.com

You could also try switching the RAM to the other slots and seeing if it helps. Provided none of the above works then theres a couple of options.

Option one. Return the RAM and make sure you buy a kit listed exactly by part number on the motherboards QVL list you will find on the manufacturers website. Pray that they work.

Option 2 We are in the weeds. I suggest you back up any important files before you do this, as bad RAM settings can corrupt Windows meaning a clean new install might be needed.

The second option is to manually set your RAM timings. It might be best to use a guide like this. You'll need a couple of programs described in the video. Typhoon Super burner and Ryzen DRAM calculator.

View: https://www.youtube.com/watch?v=1GTekAB1Zzc


Someone else might have another idea, but I'd be going with the Dram calculator. It will just take more time and you might even get the kit workig faster then its rated at in the end.



[masalcii67]

yes they are rated for 3200



[Kaamos_Llama]

Can you post up the exact part number of your RAM kit? It will be something like this : HX432C16FB3K2/16 I'm just interested to see if its on the QVL list for your motherboard. It doesnt usually matter so people are often blase about it, but sometimes it does, and I've had an XMP profile not work with my system before.

You can find the part number by looking on the box it came in or by downloading CPUZ.

Select the correct slot from the drop down and under the 'SPD' tab its this number here

You should also really try clearing CMOS first and checking out the link to the Toms Hardware article I posted before. I'm fairly sure you dont have a bad kit because you say it works perfectly at standard settings, but its worth checking.



[masalcii67]

i have 4x4gb of ram and they say my motherbord doesn't support that??



[Kaamos_Llama]

Yes I should have thought to ask. Sometimes 4 sticks is harder to run than 2.

Have you tired running them at a lower XMP profile, say 3000?

The other option would be to bump the voltages a tiny notch, but you really should be doing your own research if you are doing that.



[Lutfij]

In case anyone is wondering why running 4 sticks as opposed to two is harder on some platforms, is due to the fact that the IMC(Integrated Memory Controller) doesn't always like to be stressed. It also boils down to silicon lottery and the BIOS/AGESA microcode you're working with. Latest BIOS update for your motherboard? Which version are you on?

I'd see if going into D.O.C.P or manually inputting the timings, frequency and voltages in BIOS and see if you can move forward.



[Kaamos_Llama]

BIOS update should be the first thing and I didnt mention it, my bad OP



[masalcii67]

i bought new rams the G.Skill DDR4 Trident-Z 2x8GB 3600Mhz RGB this time my motherboard does support them butt still when i enable xmp profile 1 or 2 on 3600MHz it boots up butt running on 2133MHz.
i also tried manually overclocking butt nothing happened...



[Lutfij]

Can you walk us through how you went about inputting the numbers in BIOS? Which slots are the rams populating? You haven't gotten back to me with the BIOS version



[masalcii67]

my rams are optimized voor A2 and B2 and manually inputting the setting with the help off DRAM Calculater every setting is in order



[Lutfij]

Use the numbers found on the sticker off the stick(s) of ram. BIOS version?



[masalcii67]

i know i did my timings for 3600MHz are 16-19-19-39 1.35v and my BIOS version is the latest version 7C37v1D
when i do that i get overclocking fail error



[Lutfij]

Link to the ram kit? No offence but punctuation helps. I had to read that post more than once in order to figure out what you knew.



[masalcii67]

https://pcpartpicker.com/product/JgLwrH/gskill-trident-z-neo-16-gb-2-x-8-gb-ddr4-3600-cl16-memory-f4-3600c16d-16gtznc



[Lutfij]

What are you using to cool that processor of yours? Disable XMP, manually set only the frequency to DDR4-3200MHz and the voltage to 1.4v. Leave timings on Auto. If you can get the system to boot to GUI, stress test. Then go back into BIOS and then up the frequency to DDR4-3600MHz, same voltage.



[masalcii67]

im using corsair hydro h100i rgb platinum to cool my cpu.
i have done what u say, when i want to boot up with 3200MHz it go's in bootloop.
i have done a memtest with default settings for 4-5hours and it found 2 cpu error...



[Kaamos_Llama]

Long shot, but is the CPU overclocked at all using PBO ?



[masalcii67]

yesss



[Kaamos_Llama]

Oh. In that case put it back to stock and try again from the start.

Your motherboard is not very good for overclocking your chip, and is quite likely what is causing the problem. I assumed you were at stock. Its the very first thing you shold do if you are having problems.



[Lutfij]

I was going to ask about PBO until I thought, maybe he didn't go that far.



[Kaamos_Llama]

I assumed that if you hadn't enabled XMP, you wouldnt have overclocked the chip yet.

I always forget what they say about assumption, hopefully this will help !



[masalcii67]

how do i set everything back to stock?



[Kaamos_Llama]

Clear CMOS. I'm not sure whether Ryzen Master auto sets the overclock from startup as well, I havent used it myself yet. If so you'll have to check in the software and make sure its set to default values when you start Windows.

https://www.reddit.com/r/MSI_Gaming/comments/cqdbl3

View: https://www.reddit.com/r/MSI_Gaming/comments/cqdbl3/how_to_reset_gaming_edge_x570_mobo/


How to clear CMOS, I guess your board doesnt have jumpers or a switch so youll have to remove the battery.



[masalcii67]

Is it possible that my cpu doesn't support DDR4 3600MHz??
