Question Question I just built a PC and found a memory incompatibility - seeking advice to avoid another bad decision.

Oct 10, 2023
3
1
15
Visit site
Hello!

TL;DR - This is my first gamer PC and I picked the wrong memory, A LOT of app crashes, computer is impossible to use.

The memory manufacturer says the memory is incompatible with the motherboard. I found the Memory QVL from ASRock website (https://pg.asrock.com/mb/Intel/Z690 Phantom Gaming 4D5/index.asp#Memory) and I don't know which one is a good option.

I've been reading some bad reviews related to ddr5 5200 MHz.

Furthermore, I live in Brazil, so I have limited options in the market :(

Please help me to pick a decent memory kit :)Here is what I can get:



Memory KitPrice in USDps
XPG Lancer, RGB, 32GB (2x16GB) 6000MHz, DDR5, CL40 - AX5U6000C4016G-DCLARBK200looks like Memory QVL tested using 1 stick - should I avoid picking 2 sticks?
Kingston Fury Beast, RGB, 32GB (2x16GB), 6000MHz, DDR5, CL40 - KF560C40BBAK2-32210
Kingston Fury Beast Intel XMP, RGB, 64GB (2x32GB), 5600MHz, DDR5, CL40 - KF556C40BBAK2-64380
Corsair Vengeance, 32GB (2x16GB), 5600MHz, DDR5, CL36 - CMK32GX5M2B5600C36150
Kingston Fury Beast para Intel XMP, RGB, 32GB (2x16GB), 5600MHz, DDR5, CL40 - KF556C40BBAK2-32230
Kingston Fury Beast para Intel XMP, 32GB (2x16GB), 5600MHz, DDR5, CL40 - KF556C40BBK2-32200
My current Specs:



CPU:Intel Core i9-13900KF 3 GHz 24-Core Processor
CPU Cooler:Noctua NH-U9S chromax.black 46.4 CFM
CPU CoolerThermal Compound:Noctua NT-H2 3.5 g Thermal Paste
Motherboard:ASRock Z690 Phantom Gaming 4/D5 ATX LGA1700 Motherboard
Memory:G.Skill Trident Z5 RGB 32 GB (2 x 16 GB) DDR5-6800 CL34 Memory
Storage:Samsung 970 Evo Plus 1 TB M.2-2280 PCIe 3.0 X4 NVME Solid State Drive
Storage:Samsung 980 Pro 1 TB M.2-2280 PCIe 4.0 X4 NVME Solid State Drive
Video Card:Gigabyte EAGLE OC GeForce RTX 4080 16 GB Video Card)
Case:Lian Li O11D XL-X ATX Full Tower Case
Power Supply:EVGA 850 GQ 850 W 80+ Gold Certified Semi-modular ATX Power Supply
Monitor1:Alienware AW3423DWF 34.2" 3440 x 1440 165 Hz Curved Monitor
Monitor2:BenQ XL2430T 24.0" 1920 x 1080 144 Hz Monitor
Keyboard:Logitech G915 TKL RGB Wireless Gaming Keyboard
Mouse:Logitech PRO X Superlight 2 Wireless/Wired Optical Mouse
Headphones:JBL Quantum 800 Headset

  • Like
Reactions: Brian Boru
Oct 10, 2023
3
1
15
Visit site
don't buy or sell anything just yet.

1. what vccsa (system agent) voltage is hwinfo64 reporting ?
2. did you try running the memory at 6000/6200/6400 ?
2. get a better cpu cooler, like now.
hey! :)

Right now im running single channel, it is more stable...

1. what vccsa (system agent) voltage is hwinfo64 reporting ?



2. did you try running the memory at 6000/6200/6400 ?
yeah I tried at 6000/5800/5600, the crashes still happens
2. get a better cpu cooler, like now.
hmm the last BIOS update fixed cpu overheat, i've been runnig prime95, gpu benchmark for hours, and even cyberpunk on ultra for 1 hour (max gameplay achieved wee) and the max temp was 85c. Why do I need to get a better cooler?


memory controller voltage is on the cpu, not ram. find vccsa (system agent)

hmm the last BIOS update fixed cpu overheat, i've been runnig prime95, gpu benchmark for hours, and even cyberpunk on ultra for 1 hour (max gameplay achieved wee) and the max temp was 85c. Why do I need to get a better cooler?

probably not at advertised all core frequency. now way a 92mm cooler can cool down a 13900k. your imc overheating might be the reason for crashes as well.

Last edited:
Oct 10, 2023
3
1
15
Visit site
memory controller voltage is on the cpu, not ram. find vccsa (system agent)
I havent found vccsa but I managed to print all the infos here:
edit: system agent is my guess but it is reporting 0v

probably not at advertised all core frequency. now way a 92mm cooler can cool down a 13900k. your imc overheating might be a reason as well.
I will try to understand what you say here but looks like you know what you are talking about :D

I've done some researches and found that this is a good air cooling option for 13900k, anyway I will take a look again...
